TiM

Description

The intellegent Matrix is a 8×16 (128) array of smart RGB pixels that can be controlled from a single microcontroller pin!

Features

•
  Super bright 24-bit RGB color (not multiplexed)

•
  Expandable — make larger arrays by stacking multiple boards horizontally or vertically

•
  Control each board with 1 microcontroller pin (series mode, 128 RGB LEDs) OR

•
  Control each board with 8 microcontroller pins (1 byte, Parallel mode, 8 rows of 16 RGB LEDs each)

•
  Expand this configuration     for larger matrices. A series matrix will still be controlled with 1 control signal, and a parallel matrix by 8 signals.

•
  Very low profile – lets you make a thin matrix

•
  Compatible with Adafruit Neo Pixel Library

•
  Drive up to 25 boards with 5V 400W power supply

Specs

•
  0.6” LED spacing – horizontal / vertical

•
  Input voltage : 3V3 – 5V0

•
  Max current 2.6 Amperes / board (measured at 100% duty cycle on R, G, and B at 5V)

•
  RGB WS2811 smart pixel LEDs

Uses

•
  Large format displays

•
  Mood lighting

•
  Holiday lighting

•
  Super bright full color word clock

User Guide
