RS-485 Shield for Raspberry Pi

Description

Tip

This product is fully compatible with Raspberry Pi 4 (1GB, 2GB,4GB) and hopes you enjoy hacking with Pi 4 and all of other Pi 4 accessories.

Description

RS-485 is a cost-effective solution in serial communication networks. It can be used up to data rates at 10 Mbit/s or distances up to 1200m at lower speeds. This RS-485 Shield is a standard add-on board for Raspberry Pi. It is integrated with simple screw terminal as well as DB9 interface.

Features

• One driver and one receiver per part
• EMI noise minimization
• Transmission rate up to 2.5Mbps
• No driver slew rate limitation
• Short-circuit current limited
• Fail-Safe Applications
• Compatible : Raspberry Pi 4

Typical Applications

• Low-Power RS-485 Transceivers
• Level Translators
• Transceivers for EMI-Sensitive Applications Industrial-Control Local Area Networks
• Half-duplex applications

Pin Out

Attention:

          This module do not contain a Raspberry Pi, if you need one please check here
