Name: PIR Motion Sensor - Large Lens version
SKU: 101020060
Price: 5.75 USD
Availability: InStock

Description

PIR（Passive Infrared Detection）are used to detect motion of human movement. This version has a large lens which can support long range and wide angle. 2.54mm standard connector is easy to fix it anywhere.

The PIR Motion Sensor Series includes several products that will meet your different needs:

Product	Measuring range (theoretical value)	Features
Grove – PIR Motion Sensor	Max Distance:3-6m(3m by default) Angle:< 120°	Measuring distance and holding time adjustable response speed:0.3s – 25s
Grove-Adjustable PIR Motion Sensor	Max Distance:3-6m Angle: X=110° Y=90°	Measuring distance and holding time adjustable
Grove – mini PIR motion sensor	Max Distance:2-5m(2m by default) Angle: X=110° Y=90°	Sensitivity adjustable Mini-size
PIR Motion sensor module	Max Distance:3-7m Angle:< 120°	Sensitivity & Delay time adjustable
Grove – Digital PIR Motion Sensor	Min Distance: 3.2m Angle:< 100°	Mini-size Simple and intuitive

Want to know more about how the PIR sensor works with Arduino and Raspberry pi, please click here to view the blog. If you need tutorials for operating the sensor, please click here to view the wiki.

Features

Long-range
Wide-angle
Low consumption
DC 3.0-5.5V power supplier

Specifications

Input Voltage: DC3.0-5.5V
Current: 100uA(max)
Output signal: 0,VCC (Output high when motion detected)
Sentry Angle: 120°
Connector:3Pin 2.54mm pitch
Size： L36*W26*H21(mm)

Additional information

Weight	0,008 kg
