OV5647-62 FOV Camera Module for Raspberry Pi 3B+4B

Feature

• Compatible Raspberry Pi Camera: 5 megapixel OV5647 light-sensitive chip and fisheye lens equipped, presents 2592 x 1944 active array size, supporting Raspberry Pi 3B / 3B+ / 4
• Wider Field of View: Benefits from Fisheye Lens to achieve 62 FOV for more sense area capture
• On-module 4 Screw Holes: Convenient for attachment to surveil a large landscape
• Adjustable 3.6mm Focus Length Lens

Description

This Camera Module benefits from Fisheye Lens to achieve 62 Field of View and utilizes the OV5647 sensor to reach 2592 x 1922 active array size. The module supports Raspberry Pi 3B+4B. You can adjust its focal length and mount it on the wall with 4 screw holes. It is suitable for large-space camera shooting and perfect for high-quality large landscape surveillance.

As one important part of this camera module, the Fisheye Len produces visual distortion, projecting a characteristic convex appearance, displayed on the hemispherical screens. That is, it offers a much wider field of view capturing function to the Raspberry Pi compared to the Rectilinear Len.

The module also comes with adjustable focus length and on-module 4 screw holes, which can be placed on the top of the wall, helping you to surveil any unusual activity or movement on your property.

If you want to capture more specific or higher vision detail, we recommend other cameras, for example:

• Raspberry Pi High-Quality Camera – 12.3 Megapixel
• M12/CS mount IMX 219 CMOS Camera Module – 8 Megapixel

Application

• Large Landscape Camera Shooting

Specification

Part List

FAQ

Q: I am new to the Raspberry Pi Camera, how can I get started with it?

A: The OV5647 Series Raspberry Pi Camera Modules that Seeed presented here can be programmed just like the official one. You can refer to the Raspberry Pi official website to get started with your new modules.
