Description
The Grove- Speaker is a module which consists of power amplification and voice outputs.
Features
- Volume Adjustable
- Grove Interface
Description
The Grove- Speaker is a module which consists of power amplification and voice outputs. The loudness can be adjusted by the on-board potentiometer. With different input frequencies, the loud-speaker generates different tones. Coding the music into arduino, DIY your own music box!
Note
We’ve released an updated version of Grove – Speaker Plus for more advanced performance and better user experience.
Comparison
| Details | Grove Speaker | Grove Speaker Plus |
|---|---|---|
|
Image |
 |
.png) |
| Price | $6.90 | $10.50 |
| Speaker | Fixed | Removable |
| Quality of Speaker |  |
 |
| Size | Compact | Medium |
We have developed more than 400 Grove modules, covering a wide range of applications that can fulfill various needs. Click to explore the Grove Sensor family and get started to Grove your Idea. For all Grove users (especially beginners), we provide you with guidance PDF documents. Please download and read through Preface – Getting Started and Introduction to Grove before your use of the product.
Application
- Music Player
- Gamepad speaker
- Prompt speaker
Specifications
|
Dimensions |
130mm x90mm x12mm |
|
Weight |
G.W 12g |
|
Battery |
Exclude |
|
Working Voltage |
4.0V-5.5V |
|
Voltage Gain |
46db |
|
Band Width |
20KHz |
Part List
| Grove – Speaker | 1 |
