Grove-EL Driver

Description

Grove – EL Driver is designed for driving EL Wires.It integrates a very small inverter to drive the EL Wire, so you can easily light up the EL Wire with just one single Grove cable.

Features:

• Grove compatible interface

• 3.3V/5V Compatible

• Integrated Inverter Transformer

Specification:

• Input Current: 300mA Max (According to the load)

• Input Voltage 3~5Vdc

• Output Voltage:70~110Vpp

• Output frequency: 8~20kHz

• Supported max EL Capacitance: 15nF
